[ HITTO ] 1/4" Filter Regulator ( 02HAFAFR1 )

SPECIFICATION :

• Operating fluid : air
• Filtering element roughness : 40u
• Ensured pressure resistance : 1.5MPa
• Operating temperature range: 5~60°c
• Capacity of filter cup : 15cc
• Body material :  Aluminum alloy die-casting molding
• Container Cup : PE
• Protective Cup Cover : Iron
• Recommended lubrication oil:  ISOVG32 or At the same level of oil
• 1. The structure is delicate and compact, which is convenient for installation and application.
• 2. The pressed-in self-locking mechanism can prevent the abnormal movement of the set pressure caused by external interfere.
• 3. The pressure loss is low and the efficiency of water separating is high;
• 4. In addition to standard type, lower pressure type is optional(The highest adjustable pressure is 0.4MPa).
